K Series Fork Positioner

Applicable to the material distribution, warehousing and manufacturing industries, make the forklift driver accurately adjust the space of the forks with wide vision.

Leave a message
Specification Parameters Cases Recommendations

Specification

Wontonne Forklift Attachments K Series Fork Positioners 01

Advantages:
1. Fork positioner allows the operator hydraulically move the forks closer together or further apart, individually or together.
2. It is particularly useful when the operator has to handle a variety of pallet sizes.
3. The operator doesn’t need to manually adjust the forks, thus saving time.

Parameters

Capacity Load
Center
Model
No.
Mounting
Class
Opening
Range
Min. Truck
Carriage
Width
Carriage
Width
Fork
Pocket
Width
Vertical
Center of
Gravity
Horizontal
Center of
Gravity
Weight Effective
Thickness
kg mm O
mm
mm W
mm
S
mm
VCG
mm
HCG
mm
kg ET
mm
2500 500 FPS25K-1020A ISO 2A 260-895 895 1020 120 225 30 66 62
3000 600 FPS30K-1100B ISO 3A 305-975 935 1100 122 290 31 85 64

*With the innovation of technology, the configuration and parameters of our products are subject to change without notice; if in doubt, the specific sales confirmation of our company is the main focus
