Products / Rotators / D Series Rotator, Standard Type
Rotators

D Series Rotator, Standard Type

The Wontonne D Series Rotator (Standard Type) quickly rotates container contents 360 degrees when used with forks, hoppers and other attachments.

fitness_center Capacity
1700 kg
straighten Load Center
500 mm
monitoring Weight
188 kg
build Mounting
ISO 2A
View All Rotators
D Series Rotator, Standard Type
D Series Rotator, Standard Type - 1D Series Rotator, Standard Type - 2D Series Rotator, Standard Type - 3D Series Rotator, Standard Type - 4D Series Rotator, Standard Type - 5D Series Rotator, Standard Type - 6D Series Rotator, Standard Type - 7D Series Rotator, Standard Type - 8D Series Rotator, Standard Type - 9D Series Rotator, Standard Type - 10D Series Rotator, Standard Type - 11D Series Rotator, Standard Type - 12D Series Rotator, Standard Type - 13D Series Rotator, Standard Type - 14D Series Rotator, Standard Type - 15D Series Rotator, Standard Type - 16D Series Rotator, Standard Type - 17D Series Rotator, Standard Type - 18D Series Rotator, Standard Type - 19D Series Rotator, Standard Type - 20D Series Rotator, Standard Type - 21D Series Rotator, Standard Type - 22D Series Rotator, Standard Type - 23D Series Rotator, Standard Type - 24D Series Rotator, Standard Type - 25D Series Rotator, Standard Type - 26D Series Rotator, Standard Type - 27D Series Rotator, Standard Type - 28D Series Rotator, Standard Type - 29D Series Rotator, Standard Type - 30D Series Rotator, Standard Type - 31D Series Rotator, Standard Type - 32D Series Rotator, Standard Type - 33D Series Rotator, Standard Type - 34

Product Overview

The Wontonne D Series Rotator (Standard Type) quickly rotates container contents 360 degrees when used with forks, hoppers and other attachments.

Rotators enable a 360° container flip for necessary rotations or inversions. Widely employed in food, chemical, sanitation, recycling, smelting, casting, and other industries.

Key features & specifications:

360° rotation of contents

For forks and hoppers

Quick dumping and flipping

Hydraulic motor drive

High-quality rotating mechanism

Wide capacity range

Capacity up to 6800kg

Compatible with major forklift brands. Wontonne provides comprehensive after-sales service including technical support and spare parts.

Need More Info?

Get detailed specifications, pricing, and delivery estimates from our team.

Model Specifications

Model No Capacity (kg) Load Center (mm) Mounting Weight (kg)
RRB20D-001A 1700 500 ISO 2A 188
RRB20D-006A 2200 500 ISO 2A 300
RRB20D-007A 2200 500 ISO 2A 309
RRB30D-008A 3000 500 ISO 2A 313
RRB30D-009A 3000 500 ISO 2A 327
RRB35D-010B 3500 500 ISO 3A 390
RRB35D-011B 3500 500 ISO 3A 406
RRB50D-001B 5400 500 ISO 3A 489
RRB50D-001C 5400 500 ISO 4A 555
RRB50D-002B 5400 500 ISO 3A 537
RRB50D-002C 5400 500 ISO 4A 604
RRB54D-003C 5400 600 ISO 4A 726
RRB54D-004C 5400 600 ISO 4A 783
RRB70D-001C 6800 600 ISO 4A 924
RRB70D-002C 6800 600 ISO 4A 981
RRB70D-003C 6800 600 ISO 4A 1040
RRB72D-001D 7200 600 ISO 5A 1173
RRB100D-001D 10000 760 ISO 5A 2015
